Santak Rack PDU SBP32GB10/2-P Power Distribution Unit 32A
The SANTAK Cabinet PDUSBP32GB10/2-P power distribution unit is the ultimate solution for safe power distribution in equipment rooms, featuring 32A high-current capacity and 8000W rated power, specifically designed for demanding environments like laboratories and production workshops. The integrated aluminum alloy housing, crafted through 80 precision processes, incorporates solid-core copper busbars to reduce resistance, paired with a 10KA professional lightning protection module, ensuring stable operation under sudden current surges. The 10+2 sets of triple-flat national standard sockets use phosphor bronze contacts, withstand 120°C high temperatures, and pass 5000 insertion/extraction tests, combined with UL94-V0 flame-retardant materials, building multiple safety barriers for precision equipment.The unique L-shaped bracket supports 0-180° rotational installation, allowing flexible switching between vertical and horizontal mounting. Its 832mm compact size fits 19-inch cabinets, enabling rapid deployment with just two screws, meeting both mobile construction site needs and fixed equipment room installation requirements.
Buy Now
Product details
As the core component of cabinet power distribution systems, the SANTAK PDUSBP32GB10/2-P redefines safe power distribution with military-grade manufacturing standards. The unit features seamless copper bar conductors with a 32A current-carrying capacity, reducing contact resistance by 87% compared to traditional spliced copper bars. Paired with phosphor bronze spring-contact sockets, it maintains a temperature rise of only 13-28°C under full 8000W load, far below the national standard limit of 45°C. The innovative integrated aluminum alloy housing, treated with anodization, improves heat dissipation efficiency by 40% while withstanding 10KA lightning surge impacts, with key components certified by UL/CE/3C.The flexible configuration of 10 main sockets + 2 backup outlets supports mixed use of 10A and 16A devices. The PC/ABS composite engineering plastic shell meets V0 flame-retardant standards, ensuring zero melting risk even in dusty construction sites or chemically corrosive lab environments. The unique L-shaped bracket design breaks traditional PDU installation limits, allowing 180° free rotation in vertical mounting and requiring only 44.4mm depth for horizontal deployment, making it ideal for space-constrained cabinet retrofits.The standard SPD lightning protection module monitors overvoltage risks in real time, while dedicated junction box input terminals enable single-point fault isolation, ensuring 24/7 uninterrupted operation in production workshops. From precision servers in data centers to industrial equipment at construction sites, this power distribution unit, tested for 50,000 insertion-extraction cycles, safeguards every electrical device's critical lifeline with ultra-low contact resistance of 0.02Ω and 50N plugging force standard.Product Features
- 1. Integrated copper bar conductor design with 10mm² cross-section, improving conductivity efficiency by 30%
- 2. Professional 10KA surge protection module, compliant with IEC61643 lightning protection standard
- 3. High-temperature-resistant engineering plastic casing with UL94-V0 flame retardant certification
- 4. Supports ±90° rotation installation, compatible with various 19-inch standard rack layouts
- 5. Phosphor bronze sockets tested for 5000 insertions, contact resistance below 0.5mΩ
- 6. Aluminum alloy heat dissipation casing with optimized airflow design, temperature rise control 50% better than national standards
- 7. Supports customized services, configurable with special interfaces and installation accessories
Application Scenarios
- 3. Industrial production workshop automation equipment power distribution system
- 4. Communication base station rack equipment power distribution
- 5. Medical equipment room uninterruptible power supply
- 6. Smart building low-voltage system centralized power supply node
Product Parameters
- Model:SBP32GB10/2-P
- PDU input rated current:32A
- PDU input voltage range:110~240V
- PDU input rated power:8000W
- PDU input plug:Junction box
- PDU input cable length:None
- PDU input functional module:SPD lightning protection
- PDU output socket type:National standard flat pins
- PDU output rated current:10A/16A
- PDU output socket quantity:10+2
- Product dimensions:832*64*44.4mm
- Installation method:Vertical installation
